Lumintop FW21 X1L

Lumintop FW21 X1L Flashlight





Features



• Emitter: Single Osram KW CULNM1.TG_CN LED on a copper DTP MCPCB
• Optic: New and focusing type Optical Lens
• Lens: Glass with anti-reflective coating
• Flux: 750 lm
• Intensity: ~135900cd ANSI throw ~780m
• Modes: Three general modes, plus hidden Eco and Turbo
• Battery: One flat-top unprotected 21700 or 18650 Li-ion battery
• ** Battery is not included **
• Low-voltage and over-heat protection
• Driver: FET+7+1 driver. Low parasitic drain while OFF
• Body: Aluminum with hard-coat anodizing
• Switch: Electronic tail switch
• Ingress rating:  Equivalent to IPX8
• Weight: Approximately 114.2g without cells
• Size: 118*40*25mm
• Accessories: 1*Manual, 1*18650 battery adapter, 2*Spare 0-ring

Lumintop FW21 X1L Specifications

ANSI/NEMA FL1	Eco	Low	Med	High	Turbo
Output	10LM	40 LM	400 LM	600 LM	750 LM
Runtime	470h	16h	15h 05min	14h 30min	15s+1.5h
Distance	780m (Max)
Intensity	135,900cd (Max)
Impact Resistant	1.5m
Waterproof	IPX8, underwater 2m

Notice: The above approximate data are lab-tested by using a Samsung INR 21700 30T Li-ion battery. The runtime is accumulated due to over-heat protection, and it may vary due to the difference of environment and batteries.

Operation Instruction
General Modes: Low-Med-High; Hidden Modes: Eco, Turbo

1. ON/OFF: One click for on, press and hold for 1 second for OFF. When the light is on, tap the switch to cycle through general modes.
2. Eco: Press and hold the switch for 1 second from OFF, another click will enter the general mode.
3. Turbo: Double clicks from ON, another click will enter the general mode.
4. Instant High: Double clicks from OFF will enter High mode, another click will enter the general mode.
