EVVA Protected 16340 700mAh
EVVA Protected 16340 700mAh Lithium-ion Rechargeable Battery
Protected 16340 700mAh Li-ion battery for flashlight. In-built Seiko IC and MOSFETs to protect the battery from overcharge, over discharge and short circuit. Gold-coated PCB can ensure a better conductivity.
Specifications
|
Type |
EVVA 16340 lithium rechargeable battery protected |
|
Supplier |
EVVA TECHNOLOGY CO.,LIMITED |
|
Cell |
DLG ICR16340 3.7V 700mAh |
|
Nominal voltage |
3.7V |
|
Nominal capacity |
700mAh |
|
|
discharge at 0.2C mA |
|
Minimal capacity |
2700mAh |
|
Stanard Charge voltage |
4.30V ( Full Charged Voltage ) |
|
Standard Charge current |
350mA |
|
Charge Time(Std.) |
3 hours |
|
Discharge cut-off voltage |
2.75V |
|
Standard Discharge current |
140mA |
|
Standard Discharge cut-off current |
30mA |
|
PCB protection trip current |
about 5A |
|
Storage environment |
-20°C~60°C; Less than 1 month |
|
-20°C~60°C; Less than 3 months |
|
|
Cell Weight ) |
20 g max. |
|
Cell Dimension (approx.) |
(L)35.60mm*(D)16.70mm |
***Batteries purchased without any equipment they can operate must be shipped with ground shipping. If you purchase only batteries and no flashlights/headlamps you must select UPS/Fedex Ground unless your order meets the free shipping threshold.***
